Traefik Sablier Plugin

Automatically start containers on demand and shut them down during periods of inactivity using Traefik.

This plugin is available in the Traefik Plugin Catalog.

• Installation
• Prerequisites
• Configuration
• Usage
  • Dynamic Configuration
  • Docker
  • Docker Swarm
  • Kubernetes
• Other Reverse Proxy Plugins
  • Apache APISIX
  • Caddy
  • Envoy
  • Istio
  • Nginx
• Sponsor
• Community
• Support

Installation

Add the following snippet to your Traefik static configuration:

Copy
experimental:
  plugins:
    sablier:
      moduleName: "github.com/sablierapp/sablier-traefik-plugin"
      version: "v1.0.0"

Or using CLI arguments:

Copy
--experimental.plugins.sablier.moduleName=github.com/sablierapp/sablier-traefik-plugin
--experimental.plugins.sablier.version=v1.0.0

Prerequisites

[!IMPORTANT] You must have a reachable instance of Sablier from Traefik.

Configuration

The plugin supports various configuration options to customize its behavior. All options are configured at the middleware level.

Complete Configuration Example:

Copy
http:
  middlewares:
    my-sablier:
      plugin:
        sablier:
          sablierUrl: http://sablier:10000
          group: my-app-group
          sessionDuration: 1m
          ignoreUserAgent: curl
          dynamic:
            displayName: My Services
            showDetails: true
            theme: hacker-terminal
            refreshFrequency: 5s

Option	Type	Required	Default	Description
sablierUrl	string	Yes	http://sablier:10000	URL of the Sablier server API (must be reachable from Traefik)
group	string	Yes	-	Group name for managing multiple instances collectively >
sessionDuration	duration	No	-	Duration to keep instances running after the last request (e.g., 1m, 30s, 2h)
dynamic.displayName	string	No	Middleware name	Display name shown on the waiting page
dynamic.showDetails	boolean	No	Server default	Show detailed information on the waiting page
dynamic.theme	string	No	Server default	Theme for the waiting page (e.g., hacker-terminal, ghost, matrix)
dynamic.refreshFrequency	duration	No	Server default	How often the waiting page checks if instances are ready
blocking.timeout	duration	No	-	Maximum time to wait for instances to become ready
ignoreUserAgent	string	No	-	User Agent that should be ignored (middleware sends HTTP 200 to not wake up the container)

Usage

The plugin can be configured in different ways depending on your deployment context:

• Dynamic Configuration: Universal approach using configuration files (works with all Traefik providers)
• Docker: Label-based configuration for Docker containers (requires Traefik v3.6.0+)
• Docker Swarm: Swarm-specific configuration with centralized middleware definition
• Kubernetes: Kubernetes-native configuration using annotations and IngressRoute

Choose the section that matches your deployment environment below.

Dynamic Configuration

[!NOTE] This configuration method works with all Traefik providers (Docker, Swarm, Kubernetes, File, etc.).

Configure the plugin in your Traefik dynamic configuration:

Copy
http:
  middlewares:
    my-sablier:
      plugin:
        sablier:
          sablierUrl: http://sablier:10000  # Sablier service URL (must be reachable from Traefik)
          group: my-app-group               # Group name for managing instances collectively
          sessionDuration: 1m               # Session duration before shutting down instances
          # Only one strategy can be used at a time
          # Declare either `dynamic` or `blocking`, not both
          ignoreUserAgent: curl             # (Optional) Ignore requests with User Agent header curl to not wake up container

          # Dynamic strategy: displays a waiting page
          dynamic:
            displayName: My Title       # (Optional) Display name (defaults to middleware name)
            showDetails: true           # (Optional) Show details for this middleware (defaults to Sablier server settings)
            theme: hacker-terminal      # (Optional) Theme for the waiting page
            refreshFrequency: 5s        # (Optional) Refresh frequency for the waiting page

          # Blocking strategy: waits for services to start (up to the timeout limit)
          # blocking:
          #   timeout: 1m

Docker

[!IMPORTANT] Label-based configuration requires Traefik v3.6.0 or higher. This version introduced support for non-running containers (PR #10645), which is essential for Traefik to register your configuration while scaled to zero.

[!TIP] For a complete working example, see the docker example.

Add the following labels to the service you want to scale on demand:

Copy
whoami:
  image: traefik/whoami:latest
  labels:
    # Enable Sablier for this container
    - sablier.enable=true
    - sablier.group=whoami

    # Configure the Sablier middleware
    - traefik.http.middlewares.whoami-sablier.plugin.sablier.group=whoami
    - traefik.http.middlewares.whoami-sablier.plugin.sablier.sablierUrl=http://sablier:10000
    - traefik.http.middlewares.whoami-sablier.plugin.sablier.sessionDuration=1m
    - traefik.http.middlewares.whoami-sablier.plugin.sablier.dynamic.displayName=Whoami Service

    # Allow Traefik to route to non-running containers
    - traefik.docker.allownonrunning=true

    # Define Traefik routing
    - traefik.http.routers.whoami.rule=Host(`whoami.localhost`)
    - traefik.http.routers.whoami.middlewares=whoami-sablier

Docker Swarm

[!CAUTION] When using Docker Swarm, the middleware configuration must be defined on a service scanned by Traefik that is not scaled to zero.

This is because Traefik evicts services from its pool when scaled to 0/0, making service-level labels unavailable.

Enabling AllowEmptyServices is supposed to cover this use case but this is a known issue: AllowEmptyServices option does not work with the Swarm provider #12196

[!TIP] For a complete working example, see the Docker Swarm E2E test.

1. Deploy Sablier with Middleware Configuration

Deploy Sablier as a service and define all middleware configurations on it:

Copy
sablier:
  image: sablierapp/sablier:1.10.1
  command:
    - start
    - --provider.name=swarm
  volumes:
    - '/var/run/docker.sock:/var/run/docker.sock'
  deploy:
    labels:
      - traefik.enable=true
      # Define the Sablier middleware here
      - traefik.http.middlewares.whoami-sablier.plugin.sablier.group=my-group
      - traefik.http.middlewares.whoami-sablier.plugin.sablier.sablierUrl=http://tasks.sablier:10000
      - traefik.http.middlewares.whoami-sablier.plugin.sablier.sessionDuration=1m
      - traefik.http.middlewares.whoami-sablier.plugin.sablier.dynamic.displayName=Whoami Service
      - traefik.http.services.sablier.loadbalancer.server.port=10000

2. Configure Traefik with Swarm Provider

Enable the Swarm provider with empty services support:

Copy
traefik:
  image: traefik:v3.0.4
  command:
    - --experimental.plugins.sablier.modulename=github.com/sablierapp/sablier-traefik-plugin
    - --experimental.plugins.sablier.version=v1.0.0
    - --entryPoints.http.address=:80
    - --providers.swarm=true
    - --providers.swarm.refreshSeconds=1
  ports:
    - target: 80
      published: 8080
  volumes:
    - '/var/run/docker.sock:/var/run/docker.sock'

3. Configure Your Service Labels

Add labels to the service you want to scale on demand:

Copy
whoami:
  image: acouvreur/whoami:v1.10.2
  deploy:
    replicas: 0
    labels:
      # Enable Sablier for this service
      - sablier.enable=true
      - sablier.group=my-group

      # Enable Traefik routing
      - traefik.enable=true

      # Use Swarm load balancer to prevent service eviction
      - traefik.docker.lbswarm=true

      # Define routing and attach the middleware
      - traefik.http.routers.whoami.rule=Host(`whoami.localhost`)
      - traefik.http.routers.whoami.middlewares=whoami-sablier@swarm
      - traefik.http.routers.whoami.service=whoami
      - traefik.http.services.whoami.loadbalancer.server.port=80

⚠️ Limitations

• The blocking strategy cannot be used reliably due to how Traefik handles service eviction with empty pools
• Middleware configuration must be centralized on the Sablier service to remain accessible when services are scaled to 0

Kubernetes

⚠️ Limitations

• Traefik evicts services from its pool when no endpoints are available. Enable allowEmptyServices to prevent this.
• The blocking strategy is not yet supported due to Traefik's pod IP handling.

Refer to the Kubernetes E2E test script for a working example.

Other Reverse Proxy Plugins

Apache APISIX

Sablier integrates with Apache APISIX through a Proxy-WASM plugin, enabling dynamic scaling for your services.

Quick Start:

1. Install the Sablier Proxy-WASM plugin
2. Configure APISIX routes with Sablier plugin settings
3. Define your scaling labels on target services

📚 Full Documentation | 💻 Plugin Repository

---

Caddy

Sablier provides a native Caddy module for seamless integration with Caddy v2.

Quick Start:

1. Build Caddy with the Sablier module using xcaddy
2. Add Sablier directives to your Caddyfile
3. Configure dynamic scaling rules

📚 Full Documentation | 💻 Plugin Repository

---

Envoy

Sablier integrates with Envoy Proxy through a Proxy-WASM plugin for high-performance dynamic scaling.

Quick Start:

1. Deploy the Sablier Proxy-WASM plugin
2. Configure Envoy HTTP filters
3. Set up scaling labels on your workloads

📚 Full Documentation | 💻 Plugin Repository

---

Istio

Sablier works with Istio service mesh using the Proxy-WASM plugin for intelligent traffic management.

Quick Start:

1. Install the Sablier Proxy-WASM plugin in your Istio mesh
2. Configure EnvoyFilter resources
3. Annotate your services with Sablier labels

📚 Full Documentation | 💻 Plugin Repository

---

Nginx

Sablier integrates with Nginx through a WASM module, bringing dynamic scaling to your Nginx deployments.

Quick Start:

1. Build Nginx with WASM support
2. Load the Sablier Proxy-WASM plugin
3. Configure Nginx locations with Sablier directives

📚 Full Documentation | 💻 Plugin Repository
